Wilden T8 - 51 mm (2") Metal Pump

Introducing Wilden T8 - 51 mm (2") Metal Pump: Exclusive Distribution by Altools Services

Altools Services is proud to be the sole distributor of the renowned Wilden T8 - 51 mm (2") Metal Pump. This diaphragm pump is a high-performance, positive displacement pump designed to handle a variety of fluids with efficiency and reliability.

Key Features:

• High Flow Rate: Up to 617.0 LPM (163 GPM)
• Maximum Pressure: 8.6 BAR (125 PSI)
• Versatile Wetted Housings: Available in Aluminum and Cast Iron
• Robust Non-Wetted Housings: Constructed from durable materials like Aluminum and Brass
• Superior Suction Lift: 6.4 m (21') Dry, 9.5 m (31') Wet
• Handles Solids: Maximum diameter of 6mm (1/4")
• Variety of Elastomer Options: Suitable for various temperature ranges

Technical Specifications:

• Flow Rate: 617.0 LPM (163 GPM)
• Maximum Pressure: 8.6 BAR (125 PSI)
• Wetted Housings:
  • Aluminum: 33.1 kg (72.0 lbs)
  • Cast Iron: 52.4 kg (114.0 lbs)
• Non-Wetted Housings:
  • Center Block: Aluminum
  • Air Valve: Brass
• Maximum Suction Lift Capability:
  • Dry: 6.4 m (21')
  • Wet: 9.5 m (31')
• Maximum Diameter Solids: 6mm (1/4")
• Elastomer Options and Temperature Limits:
  • Buna-N®: -12.2°C to +65.6°C (+10°F to +150°F)
  • Neoprene: -17.8°C to +93.3°C (0°F to +200°F)
  • EPDM™: -51.1°C to +137.8°C (-60°F to +280°F)
  • Polyurethane: -12.2°C to +65.6°C (+10°F to +150°F)
  • Saniflex™: -28.9°C to +104.4°C (+20°F to +220°F)
  • PTFE: +4.4°C to +104.4°C (+40°F to +220°F)
  • Viton®: -40°C to +176.7°C (-40°F to +350°F)
  • Wil-Flex™: -40°C to +107.2°C (-40°F to +225°F)

Applications:

• Chemical processing
• Food and beverage industry
• Pharmaceutical manufacturing
• Wastewater treatment
• Mining operations
• Oil and gas industry
• General industrial use

Keywords:

• Wilden T8 Pump
• Diaphragm Pump
• Positive Displacement Pump
• Fluid Handling
• Industrial Pump
• Chemical Pump
• Wastewater Pump
• Mining Pump
• Oil and Gas Pump
• Altools Services

Tags:

#WildenT8 #DiaphragmPump #PositiveDisplacementPump #FluidHandling #IndustrialPump #ChemicalPump #WastewaterPump #MiningPump #OilAndGasPump #AltoolsServices

For more information or to place an order, contact Altools Services, the exclusive distributor of Wilden pumps, and ensure your operations benefit from the best in pumping technology.

Weight and Dimensions:

• Weight: Aluminum: 33.1 kg (72.0 lbs), Cast Iron: 52.4 kg (114.0 lbs)
• Dimensions: [Please provide the specific dimensions if needed]
