Streamlined design makes you feel very comfortable to hold. Large LCD display is very convenient for you to read the data.
Accurate measurement makes the reading of this distance meter very precise. It has balanced blisters, allowing you to confirm whether it is level during the measuring.
Made of ABS material, this product is very durable to use.
The length of this product is 11.5cm, the width is 5cm and the height is 2.3cm.
It is suitable for workshop, factory, industry and so on.
Specification
Measuring Accuracy :±1.5mm
Measuring Unit:m,ft,in
Laser type:620/690nm
Single Measurement time:0.25s
Operating Temperature:0~+40
Storage Temperature:20~+65℃
Batteries:AAA(Alkaline).2x1.5V
Measurements Per Battery Set:>8000
Weight (without Batteries):Approximately 82g
Dimensions (L×W×H):115x50X23mm
Laser auto switch off:30s
Instrument Auto. Switch off:180s
NOTE
Please DO NOT stare into beam at any time when operating this product!
Please avoid kids to use the meter
Features
Laser class: Ⅱ class,<1mW
Laser range:0.05m --60m
Single measurement
Max min measurement
Continuous measurement
Area / volume / Pythagoras
Plus and minus
Metre /ft/in switch
Measuring reference
Buzzer indicator
History data records:99 Groups
Data clean up
Error message code
Battery indicator
Digital leave(angle measuring)
Package Content:
1×40M Laser Distance Meter
1×User Manual
1×Holding Rope
1×One Years Warranty
Basic function | range |
Range | 0-60m |
Accuracy (typical value) | ±2mm |
Unit | m/in/ft |
Laser class | class 2 (Ⅱ) |
Laser power | <1mW |
Laser wavelength | 635nm |
Indication of intensity | |
Area | |
Volume | |
Indirect | pythagorea |
Single/continuous measurement | |
Add and subtract measurement | |
Max/Min | |
Multiple lines display | 4 lines |
Date store | 20 sets |
Reference edge | top, middle, bottom, pole |
Backlight | white |
Buzzer function | |
Error report function | |
Battery life | >5000 |
Power display | full, medium, low |
Tripod screw | |
Dustproof/waterproof rate | IP54 |
Store temperature | -20 to 65°C |
Working temperature | -10 to 40°C |
Battery | type AAA 2*1.5V |
Body colors | red+ gray |
Weight | 178g (incl battery) |
Body size | 115*52*33mm |
1 x Infrared Distance Meter
1 x Sling
1 x Cloth Bag
1 x English User Manual
